STAR ALDL1201 recessed garden wall lights led recessed stair lights

ALDL1201

CRI
Ra≥92/97
Beam angle
N/A
CCT
2700K/3000K/4000K
  • TEXTURE WHITE

  • TEXTURE BLACK

Share
Technical Parameter
  • Characteristics
    INSTALLATION
    Wall Recessed
    Adjustability
    Fixed
    Material
    Aluminum Alloy
    Color temperature
    2700K/3000K/4000K
    Beam angle
    N/A
    Optics
    Lens
    IP
    IP67
    Warranty(Year)
    5-Year
  • Photometric Result
    Light source
    COB
    Luminous flux
    100lm
    CRI
    Ra≥92/97
    UGR
    <12
    LED Qty
    1
    Energy Class
    F
    LM80
    L90B10>50000
    McAdam
    SDCM <3
  • Electrical Specifications
    Power
    2W
    Input current
    700mA
    Power supply
    Exclude LED power supply 700mA/Max.3V
    Class
    III
  • Dimensions
    Overall Dimension
    ø50*39mm
    Cutout
    ø40mm
    Thickness of mounting surface
    >6mm
    Recessed Depth
    45mm
    Weight
    -
