ROBO ALDL1563 Square recessed adjustable spotlight

ALDL1563

CRI
Ra≥92/97
Beam angle
15°/24°/38°/60°
CCT
2700K/3000K/4000K
  • TEXTURE WHITE

  • TEXTURE BLACK

Share
Technical Parameter
  • Characteristics
    INSTALLATION
    Ceiling Recessed
    Adjustability
    0° to 18° tiltable, 350° rotatable
    Material
    Aluminum Alloy
    Color temperature
    2700K/3000K/4000K
    Beam angle
    15°/24°/38°/60°
    Optics
    Lens
    IP
    IP20
    Warranty(Year)
    5-Year
  • Photometric Result
    Light source
    COB
    Luminous flux
    3*630lm
    CRI
    Ra≥92/97
    UGR
    <12
    LED Qty
    1
    Energy Class
    F
    LM80
    L90B10>50000
    McAdam
    SDCM <3
  • Electrical Specifications
    Power
    3*7W
    Input current
    350mA
    Power supply
    Exclude LED power supply 350mA/3×Max.19V
    Class
    III
  • Dimensions
    Overall Dimension
    ø157*62*83mm
    Cutout
    ø150X57mm
    Thickness of mounting surface
    1-20mm
    Recessed Depth
    83mm
    Weight
    -
