VERO ALDL1438 trimless recessed downlight anti glare downlight
ALDL1438
CRI
Ra≥92/97
Beam angle
15°/24°/36°/50°
CCT
2700K/3000K/4000K
-
TEXTURE WHITE
-
TEXTURE BLACK
Condividi
Technical Parameter
-
CharacteristicsINSTALLATIONCeiling RecessedAdjustabilitynot adjustabilityMaterialAluminum AlloyColor temperature2700K/3000K/4000KBeam angle15°/24°/36°/50°OpticsLensIPIP20Warranty(Year)5-Year
-
Photometric ResultLight sourceCOBLuminous flux560lm/780lmCRIRa≥92/97UGR<12LED Qty1Energy ClassFLM80L90B10>50000McAdamSDCM <3
-
Electrical SpecificationsPower7W/10WInput current350mA/500mAPower supplyExclude LED power supply 350mA/500mA/Max.19VClassIII
-
DimensionsOverall Dimension55x74mmCutoutø68-71mmThickness of mounting surface2-38mmRecessed Depth74mmWeight-
